Customer Display
The Customer Display is a twenty character two line vacuum fluorescent
display (VFD). It consists of a VFD and VFD controller. There is a serial
version controller and a USB controller. The actual VFD is common to the
serial and USB versions.
Serial Version
Fingerprint Reader
There is a fingerprint reader in the USB version and none in the serial version.
General Description-FDU01B is a PC peripheral FRD (Fingerprint Recognition
Device) for USB (Universal Serial Bus) connections.
Video Interface Connector The video interface connector is a High density 15 pin type
HD-15.
Indicator Lamps The LCD display shall provide an indicator lamps to give
the status of the Power Management System
Audio Jack Provides for audio input signal to the stereo speakers
mounted in the 1229L.
Optical Parameters
Characters per row
20
Number of rows
2
Character
configuration
5x7 dot matrix
Character Height 9.5 mm
Character width 6.2 mm
Character
configuration
ASCII
Character color Blue green
MTBF 300,000 hours
