1-2 Elo Entuitive Touchmonitor User Guide
The credit card reader reads all three stripes on a standard credit card or drivers
license. The credit card is read by sliding the credit card, stripe side toward the
display through the credit card reader forward or backward. There is a serial
credit card reader and a USB credit card reader.
The Hub provides 4 internal USB ports to be used by the credit card reader, the
fingerprint reader, the touchscreen, and the customer display. The hub also
supplies two USB ports to the outside of the back of the 1229L for external use.
The hub is only used by the USB version of the 1229L. The 1229L is powered
by 12 VDC from a universal type power supply brick.
Detailed LCD Display Performance Requirements
2.1” TFT LCD Display Panel
Display Format: 1800 x 600
Display area 12.1” 246.0mm (H) x 184.5mm (V)
Pixel Pitch 12.1” 0.3075mm (H) x 0.3075mm (V)
Contrast Ratio 300 typical
Brightness 300 nits typical with no touchscreen;
246 nits with
AccuTouch
; 276 nits with IntelliTouch; 276 nits
with IR
Accutouch Transmission 82% typical
IntelliTouch Transmission 92% typical
IR Touchscreen Transmission 92% typical
Response Time Tr = 30 msec/Tf = 20 msec typical
Display Color 16 million colors with dithering
Horizontal Viewing Angle +/- 60 degrees typical at CR=10
Vertical Viewing Angle -50/+40 degrees typical at CR=10
