MODEL IDENTIFICATION
LD9 __ __ __ - __ __
X = Double Sided Display
PT = Pass Thru
25 = DB25F connector to computer
POWER ADAPTER
0 = 120VAC*
COMMAND SET 1 = 220VAC
0 = LOGIC CONTROLS*
1 = LOGIC CONTROLS SERIAL/PARALLEL INTERFACE
WITH PASS-THRU 0 = SERIAL 9600 BAUD*
2 = SPECIAL COMMAND SET 1 (Aedex emulation) 1 = SERIAL 600 BAUD
3 = SEPCIAL COMMAND SET 2 (Noritaki emulation) 2 = SERIAL 1200 BAUD
4 = SPECIAL COMMAND SET 3 (Epson D202 emulation) 3 = SERIAL 2400 BAUD
5 = SPECIAL COMMAND SET 4 (Ultimate PD1100XL/XLT) 4 = SERIAL 4800 BAUD
9 = OPOS COMMAND SET 5 = SERIAL 19200 BAUD
9 = PARALLEL INTERFACE
* Default Values
** Call for description of Command Sets
CARTON CONTENTS
1. Pole display, pre-assembled.
2. Interface cable, comes with a DB9F connector (to computer) and a
DIN6F connector (to pole display) as standard equipment.
Optional DB25F connector (to computer) is available.
Note: This cable is only supplied with standard serial pole displays
with no pass-thru function. Other interface options will have
different cables.
3. Transformer adapter 120VAC to 6.0VAC (optional 220VAC).
4. Metal base plate with mounting hardware.
5. Quick Installation Guide.
