2-11
Serial Interface Connection
Your touchmonitor comes with one of the following touchscreen connector
cables: Serial (RS-232) cable or USB cable. (For Windows 98, 2000, Me and
XP systems only.)
To set up the display, please refer to the following figures and procedures:
Remove the Back Cover
The cables are connected at the back of the monitor.
• To remove the cover, grasp the lip of the cover and pull towards you until it
snaps off.
back cover
