Elo TouchSystems ET1229L Series User Manual

Section 3. Commands
21
rawsend
Function
Send arbitrary data to the device.
Syntax
/rawsend x
x is an arbitrary string which is transmitted directly to the device. The string x is passed
as-is to the device, except for ‘\’ which is used as an ‘escape’ character:
• \r is converted to <CR>
• \n is converted to <LF>
• \\ is converted to \
• \xhh is converted to a character with ASCII value hh (always two hex digits),
e.g., \x20 is converted to a space.
Errors
none
Remarks
This command as with the other raw commands supports any features that have not been
implemented in the standard set of commands. Note: the driver inserts appropriate framing
characters, e.g., <stx> and <etx>.
Example
To change the default message 00 to show “Welcome to Our Bank” on two lines of the
IntelliPIN:
Command
/rawsend 5100Welcome to\x1COur Bank<LF>
Response
none
rawxact
Function
Execute a send/receive transaction with the device in raw mode.
Syntax
/rawxact x
x is an arbitrary string which is transmitted directly to the device. The string x is passed
as-is to the device, except for ‘\’ which is used as an ‘escape’ character:
• \r is converted to <CR>
• \n is converted to <LF>
• \\ is converted to \
• \xhh is converted to a character with ASCII value hh (always two hex digits),
e.g., \x20 is converted to a space.
Errors
/rawxact 45<LF>
If a command is already pending.
/rawxact 82<LF>
If the command was canceled by the user (e.g., with CLEAR key)
Remarks
This command is a combination of /rawsend and /rawrecv. It sends the supplied data to the
device, overrides the default processing of the next message that comes from the device and
returns it to the application as a /rawxact response. After the response is returned (or
canceled), the driver switches to normal operation. The syntax for this command is identical
to the syntax of the /rawsend command; the syntax of the response is identical to the
/rawrecv response.
Example
To load a master key of 23AB4589EF6701CD into the IntelliPIN:
Command
/rawxact 9423AB4589EF6701CD<LF>
Response
/rawxact 00 940<LF>
