16
GENERAL SPECIFICATIONS
LD9000 LD900X
OPTICAL:
Number of rows 2 2 x 2 sides
Number of digits/row 20 20
Dot matrix 5 x 7 5 x 7
Digit height) 0.374in. (9.5mm) 0.374in. (9.5mm)
Digit width 0.244in. (6.2mm) 0.244in. (6.2mm)
Character config. ASCII ASCII
Brightness (typical) 900 cd/m
2
900 cd/m
2
Display color Blue-Green Blue-Green
MTBF (hours) 300,000 300,000
MECHANICAL:
Weight 2.7 lb. 2.7 lb.
Dimensions (in inches) (w x h x d) (w x h x d)
Display head 8.50 x 3.37 x 1.75 8.50 x 3.37 x 1.75
Rectangular base 2.12 x 2.0 x 2.25 2.12 x 2.0 x 2.25
Base plate 4.0 x 0.09 x 8.0 4.0 x 0.09 x 8.0
Overall height (typical) 24 24
ELECTRICAL:
Adapter input power 120VAC, 60Hz; optional 220VAC, 50Hz
Adapter output power 7.5VAC, 1000mA
ENVIRONMENTAL:
Operating temperature 0 to +50
o
C
Storage temperature -20 to +70
o
C
Relative Humidity 80%, non-condensing
Vibration (10 to 55 Hz.) 4G’s
Shock 40G’s
CABLES & CONNECTORS:
Serial
Display cable 6-pin DIN (male)
Interface cable 6-pin Din (female)
DB9 (female); optional DB25 (female)
Phone jack (male)
Power adapter Phone jack (female)
Parallel
Display cable DB25 (female)
