SecuGen _______________________________________________________ Products -7
PC Peripheral Type,
USB Fingerprint Recognition Devic
e
FDU02
SGD
0
3
-
03210001
A
SecuGen FDU02
Mechanical Dimensions(OPP02M)
Optical Specification
Hardness of prism surface 750Hk
Resolution 500 ± 10 PPI
Effective Sensing Area
12.7mm (
x ) x 14.9mm ( y )
Effective Pixel Array 400 x 300 (260 x 300 After Correction on X-axis)
Image Aspect Ratio
0.85 (x / y)
Magnification along x-direction 1.00000
Magnification along y-direction 0.641
Non-linear Distortion of Image <3%
Ambient Light Condition >5000 Lux
x
y
