2-22 Elo Entuitive Touchmonitor User Guide
• Connect one end of the USB cable to the rear side of the computer and the
other to the LCD monitor. Secure the cable under the cable management clip.
• The USB cable is for optional touch, MSR, CD and Finger Print Reader.
Only one USB cable is needed because the device contains a self powered
USB 1.1 Hub. Two self powered ports are available for running other USB
devices. For touch only, no USB Hub is present.
USB cable
cable management
clip
self powered USB 1.1 Hub
