Eloma BACKMASTER EB 30 - Functional Parts of the Eb 30; Mt, Eb 30 Xl

Description of the device - functional parts, operation and displays
22
4.2 FUNCTIONAL PARTS OF THE EB 30
MT
, EB 30 XL
MT
Fig. 5: Main components of the EB 30
MT
, EB 30 XL
MT
(in this case right-hinged)
1 Door latch and door handle
2 Inner window pane
3 Baking chamber door
4 Baking chamber
5 Water tank (optional - see section 3.4.1)
6 USB connection port (on the side of the operating panel)
7 Fan wheel, heater with protective grating
8 Operating panel with touch display screen
9 On/Off key
10 Emergency release (see section 3.3)
11 Door lock
12 Supply air opening (at the rear of the device)
13 Exhaust air pipe
14 Door seal
15 Rack, right/left
1
2
11
4
14
8
9
12
7
15
3
6
5
13
10
