106 VoIP Subscriber Gateways
- Port number – port number assigned to the subscriber unit;
- Local number – phone number, assigned to the subscriber unit;
- Port state – subscriber unit status.
The list of possible state:
hangup – handset is hung up;
hangdown – handset is hung down;
dial – dialing a phone number of callee;
calling – call to the remote side (attempt to establish connection);
ringback – ringback tone will be sent into the line (for outcoming call);
talking – connection is established from the remote side;
ringing – ring voltage is transmitted to the line (when incoming call is received);
holding – remote subscriber is put on hold;
holded – port is put on hold by remote side;
3way call – three-way conference;
testing – test of subscriber line.
- Remote number – when connection is established, this field displays the number of
opposite subscriber;
- Registration – when registration on SIP server is successful, this field displays
registration time. If registration is failed, the field will display ‘No registered’ record;
- Registrar address – SIP server address of registered subscriber;
- Line test – start parameter test corresponding to the subscriber line port.
Port test
‘Test’ button opposite each of ports allows you to test parameters
corresponding subscriber line port. Click this button to begin test (test continues
about 1 minutes). When test is finished, you may click the ‘Result’ button to view test
results that contain the following information:
