51 VoIP Subscriber Gateways
To add rule in the table, click ‘Save changes’ button. To store settings into the non-volatile
memory, click Apply button.
The changes in the submenu are effective immediately after clicking ‘Apply Changes’
button. Device reboot is not required.
2.2.4 The ‘Static routes’ submenu
Use the menu to set up static device routs and display current routing table.
Routing table description:
- Destination – IP-address of destination network;
- Gateway – IP-address of gateway for connection to destination network;
- Genmask – subnet mask of destination network;
- Flags – route flag:
 G – route uses a gateway;
 U – route is active;
 H—the destination is a separate host;
 D—the route was created after receiving a redirected ICMP message;
 M—the route was changed by a redirected ICMP message;
 !—an inactive route, packets will be rejected;
- Metric – number of steps (hops) to destination place;
- Ref – maximum number of data which the system will be able to receive in one packet
from the remote computer;
- Detection (Use) – specify the value that is used for establishing a connection;
- Interface (Ifase) – network interface that the routs lie through.
