ELTEX TAU-4.IP User Manual

15 VoIP Subscriber Gateways
Wireless interface parameters
3
Standards
802.11 b/g/n
Frequency range, MHz
2400 ~ 2483,5
Modulation
BPSK, QPSK, 16 QAM, 64 QAM, DBPSK, DQPSK, CCK
Data transfer rate, Mbps
802.11b(CCK): 1, 2, 5.5 ,11
802.11g(OFDM): 6, 9, 12 , 18, 24, 36, 48, 54
811n (HT20, 800ns GI): 130, 117, 104, 78, 52, 39, 26, 13
802.11n (HT40, 400ns GI): 300, 270, 240, 180, 120, 90, 60,
30
802.11n (HT40, 800ns GI): 270, 243, 216, 162, 108, 81, 54,
27
Maximum transmitter output power
802.11b: 16 dBm
802.11g: 11dBm
802.11n(20MHz MCS0/8): 19 dBm
802.11n(20MHz MCS7/15): 12 dBm
802.11n(40MHz MCS0/8): 19 dBm
802.11n(40MHz MCS7/15): 11 dBm
Receiver sensitivity
802.11b: -83 dBm
802.11g: -70 dBm
802.11n(20MHz MCS7): -67 dBm
802.11n(20MHz MCS15): -66 dBm
802.11n(40MHz MCS7): -65 dBm
Data protection
64/128/152-bit WEP data encryption;
WEP, TKIP and AES
Control
Remote control
Web interface, Telnet, SSH, SNMP, TR-069.
Access restriction
password
General parameters
Power supply
12V DC power adapter
Power consumption
TAU-4.IP
max 11 W
TAU-8.IP
max 16 W
TAU-8.IP-W
max 16.5 W
Operation temperature range
from +5 to +40°С
Relative humidity at 25°С
up to 80%
Dimensions
218х120х49 mm
Weight
up to 0,3 kg
_______________________________________
3
For TAU-8.IP-W only
