User Manual QT series generation 2.5, ID 2021, rev 3.2, January 14, 2022
Eltorque recommends using 10 mm² / 8 AWG for the backbone as a
minimum.
Open the interface box as described in chapter 4.4 Cable connection
overview.
There is a pair of WAGO 221-412 (or similar) splicing connectors one for the
ground conductor and one for the hot conductor. Leads in the interface box
are black and red for ground and hot conductors respectively. The splicing
connector accepts 0.14 mm² - 4 mm² / 24 AWG to 12 AWG conductor sizes.
Strip conductor to 11 mm insert the conductor in the splicing connector and
secure it.
For connecting the main power supply follow the description in chapter 4.6
Power supply connection
