The Dual CAN actuator is mounted and connected in the same way as the
standard actuators, see Chapter 4 Mounting and Installation on page 35. The
power connections are done in the same way as for the standard actuators, see
Figure 25: Power supply connection QT250 and QT800 on page 40.
Note! There must be a termination between pins A5 and B5 on the Dual CAN connector
X1, see Figure 41. The termination cable must be connected to all nodes in the
ring.
Actuators with incorrect termination might cause communication errors.
Figure 41: Dual CAN connectors
Figure 42 shows a typical dual CAN network with termination for n+2 nodes and
two CAN controllers.
Figure 42: Dual CAN network connection
