446

Celerra Network Server Command Reference Manual

The server Commands

The <netmask> is an optional field for network addresses. In case a

netmask is not specified a netmask will be assigned based on the class

of the address and addresses assigned on the system. A <netmask> of

0.0.0.0 or 255.255.255.255 is invalid in the case of net routes. The

default for the route is net.

{-add | -delete} host <dest> <gateway>

Adds or deletes a routing entry to a particular host as specified by the

optional keyword host (net is the default) to the specified destination

and gateway address. The <dest> argument represents the specific

host for the routing entry, while the <gateway> argument indicates

the network gateway to which packets should be addressed.

By default, a netmask of 255.255.255.255 is assigned to host routes.

SEE ALSO Configuring and Managing Celerra Networking, server_netstat,

server_ifconfig.

EXAMPLE #1 To list the routing table for server_2, type:

$ server_route server_2 -list

server_2 :

net 128.221.253.0 128.221.253.2 255.255.255.0 el31

net 128.221.252.0 128.221.252.2 255.255.255.0 el30

net 172.24.102.0 172.24.102.238 255.255.255.0 cge0

host 127.0.0.1 127.0.0.1 255.255.255.255 loop

Where: The output displayed is as follows:

EXAMPLE #2 To create a host routing entry, type:

$ server_route server_2 -add host 10.10.1.2 172.24.102.77

server_2 : done

EXAMPLE #3 To create a default gateway for all unspecified destinations, type:

$ server_route server_2 -add default 172.24.102.254

server_2 : done

EXAMPLE #4 To add a network routing entry with a netmask, type:

$ server_route server_2 -add net 192.162.0.0 172.24.102.238 255.255.0.0

server_2 : done

EXAMPLE #5 To delete a routing entry, type:

$ server_route server_2 -delete host 10.10.1.2 172.24.102.77

server_2 : done
