Section 4: Operation
Operation
Section 4: Operation
Figure 4-1 TEC2 Controller
4.1 Local Display Module
Display Module with Bluetooth
®
- Model 87340.
See Appendix for Specifications.
The Local Display module consists of the following as shown in Figure 4-2:
• Graphics Display
• Message Center
• Control Knob and Selector Knob
• Three LEDs
Figure 4-2 Local Display Module (LDM)
LEDs
Graphics Display
Message Center
Control Knob
Selector Knob
