5.5.1 Passcode Entry
The actuator is shipped with “000” as a passcode. To change the passcode see
Section 5.5.11, Passcode Setup.
To enter the passcode:
1. At the “CHANGE SETTINGS?” prompt answer “YES.” “ACCEPT PASSCODE
CHARACTER 1? X” will appear. “X” will be ashing. “X” is the rst “left
most” character in the passcode.
2. If this character is correct, select YES. If not select NO. Use NO to
increment from 0-9 and then A-Z until the correct character is displayed.
Select YES. The second character will ash.
NOTE:
When “Z” is displayed the data will rollover to “0” and
continue incrementing.
3. Repeat Step No. 2 for the second and third characters.
NOTE:
If the passcode is not the correct passcode, the display will return to
“CHANGE SETTINGS?” display. See Figure 5-5.
