Emerson Bettis 500 - Figure 5-13-4 Analog Output 2 Calibration Setup

February 2018
Installation and Operation Manual
E2K-405-0218 Rev. 2
64
Section 5: Customizing Actuator Settings
Customizing Actuator Settings
Figure 5-13-4 Analog Output 2 Calibration Setup
Increase Value
0.01 mA
Calibrate
4MA?
Is External Meter
Connected?
NO
NO
Figure 5-13-5 Analog Output 2
Calibration Setup
YES
YES
Decrease Value
0.01 mA
YES
YES
Accept 4MA
Setting?
YES
Return to Analog Setup?
In Figure 5-13
NO
NO
Calibrate
20MA?
Is External Meter
Connected?
NO
YES
YES
YES
Accept 20MA
Setting?
YES
NO
Increase Setting
0.01MA?
NO
Decrease Setting
0.01MA?
Calibrate
AO#2
4-20MA?
NO
OR
NEXT
NEXT
Increase Value
0.01 mA
YES
Decrease Value
0.01 mA
YES
Increase Setting
0.01MA?
NO
Decrease Setting
0.01MA?
NO
OR
NEXT
NEXT
