a. After writing all of the changes to the meter’s configuration, open the Monitor
(Detailed View) and verity the meter is acquiring data, the transducers have
good signals and flow profiles for the all of the chords displayed.
b. Collect and save a Maintenance Log and verify the meter is optimally performing.
Save the meter configuration file. If communicating with the meter via Modbus
or HART, manually update the parameters (see Section 3.3.5).
3.5 Transducer cable removal and installation
Daniel 3410 Series Ultrasonic Gas Flow Meters have blue transducer cables and a
transducer cable nut that threads directly into the back of the transducer holder. The
cables use plastic glands that are installed on the meter’s Base Enclosure.
Note
Make a note of the exiting cabling path layout to allow proper tie-wrap configuration later in this
procedure.
Meter repairs
62 Gas Ultrasonic Flow Meters
