Parameter structure
Keypad and display
Parameter x.00
Parameter
description
protocol
Performance
R/W
Figure 2-3 Display modes
Status
Mode
(Display
not
format
Advanced parameter
descriptions
Serial comms
flashing)
To enter Parameter
Timeout** Timeout** Timeout**
Mode, press key or
Parameter
Mode
(Upper
display
flashing)
Use * keys
to select parameter for editing
To enter Edit Mode,
press key
RO
parameter
When returning
to Parameter
Mode use the
*
keys to select
another parameter
to change, if
required
To return to
Status Mode,
press key
Temporary
Parameter
Mode
(Upper display
flashing)
To exit Edit Mode,
press key
Edit Mode
(Character to be edited in lower line of display flashing)
Change parameter values using keys.
* Can only be used to move between menus if L2 access has been enabled Pr 11.44 ( SE14, 0.35 )
**Time-out defined by Pr 11.41 (default value = 240 s).
Figure 2-4 Mode examples
Parameter
View Mode
Status Mode
Healthy Status
Alarm Status Trip Status
Menu 5. Parameter 5
Pr 5.05 value
Do not change parameter values without careful
consideration; incorrect values may cause damage or a
safety hazard.
Drive status = tripped
Trip type (UV = undervolts)
WARNING
NOTE
When changing the values of parameters, make a note of the new
values in case they need to be entered again.
NOTE
For new parameter-values to apply after the AC supply to the drive is
interrupted, new values must be saved.
