C Using a Field Communicator with the
transmitter
C.1 Basic information about the Field Communicator
The Field Communicator is a handheld configuration and management tool that can be used with a variety of
devices, including Micro Motion transmitters. It provides complete access to transmitter functions and data.
Field Communicator documentation
Most of the instructions in this manual assume that you are already familiar with the Field Communicator and
can perform the following tasks:
• Turn on the Field Communicator
• Navigate the Field Communicator menus
• Establish communication with HART-compatible devices
• Send configuration data to the device
• Use the alpha keys to enter information
If you are unable to perform these tasks, consult the Field Communicator manual before attempting to use
the Field Communicator. The Field Communicator manual is available on the documentation CD or at
www.emerson.com.
Field Communicator menus and messages
Many of the menus in this manual start with the On-Line menu. Ensure that you are able to navigate to the
On-Line menu.
As you use the Field Communicator with a Micro Motion transmitter, you will see a number of messages and
notes. This manual does not document all of these messages and notes.
Important
The user is responsible for responding to messages and notes and complying with all safety messages.
C.2 Connect with the Field Communicator
A connection from the Field Communicator to your transmitter allows you to read process data, configure the
transmitter, and perform maintenance and troubleshooting tasks.
Prerequisites
The following HART device description (DD) must be installed on the Field Communicator :
4200 Dev v1 DD V1 or later.
Important
If the HART security switch is set to ON, HART protocol cannot be used to perform any action that requires
writing to the transmitter. For example, you cannot change the configuration, reset totalizers, or perform
calibration using the Field Communicator with a HART connection. When the HART security switch is set to
OFF, no functions are disabled.
Configuration and Use Manual Using a Field Communicator with the transmitter
MMI-20048166 April 2019
Configuration and Use Manual 215
