When you first enter the configuration screen, the current configuration value is displayed in decimal
notation, and the active character is flashing. If the value is positive, no sign is displayed. If the value is
negative, a minus sign is displayed.
Procedure
• To change the value:
a) Activate Select until the digit you want to change is active (flashing).
Select moves the cursor one position to the left. From the leftmost position, Select moves the
cursor to the rightmost digit.
b) Activate Scroll to change the value of the active digit.
c) Repeat until all digits are set as desired.
• To change the sign of the value:
• If the current value is negative, activate Select until the minus sign is flashing, then activate Scroll until
the space is blank.
• If the current value is positive and there is a blank space at the left of the value, activate Select until the
cursor is flashing under the blank space, then activate Scroll until the minus sign appears.
• If the current value is positive and there is no blank space at the left of the value, activate Select until
the cursor is flashing under the leftmost digit, then activate Scroll until the minus sign appears.
• To move the decimal point:
a) Activate Select until the decimal point is flashing.
b) Activate Scroll.
The decimal point is removed from its current position.
c) Activate Select and watch the position of the decimal point.
As the cursor moves to the left, the decimal point will flash between each pair of digits, up to a
maximum precision of four (four digits to the right of the decimal point).
Tip
If the position is not valid, the decimal point is not displayed. Continue to activate Select until the
decimal point appears at the right of the displayed value.
d) When the decimal point is in the desired position, activate Scroll.
The decimal point is inserted at its current position.
• To save the displayed value to transmitter memory, activate Scroll and Select simultaneously and hold
until the display changes.
• If the displayed value is the same as the value in transmitter memory, you will be returned to the
previous screen.
• If the displayed value is not the same as the value in transmitter memory, SAVE/YES? flashes on the
display. Activate Select.
• To exit the menu without saving the displayed value to transmitter memory, activate Scroll and Select
simultaneously and hold until the display changes.
• If the displayed value is the same as the value in transmitter memory, you will be returned to the
previous screen.
