4 Introduction to configuration and
commissioning
4.1 Default values
Default values for your SGM meter are configured at the factory.
Important
Default values are based on your purchase order options. Therefore, the default values described in the
following tables may not be the factory default values configured for your system. For absolute accuracy,
refer to the configuration sheet that was shipped with your meter.
4.1.1 SGM default mA scaling values
Table 4-1: Primary variables
Variable Default 4 mA Default 20 mA
Specific gravity for calibration range 1 0 0.4
Specific gravity for calibration range 2 0 0.4
Specific gravity for calibration range 3 0 0.4
Specific gravity for calibration range 4 0 0.4
Molecular weight for calibration range
1
0 g/mol 28.96469 g/mol
Molecular weight for calibration range
2
0 g/mol 28.96469 g/mol
Molecular weight for calibration range
3
0 g/mol 28.96469 g/mol
Molecular weight for calibration range
4
0 g/mol 28.96469 g/mol
Sensor time period 400 us 1200 us
Table 4-2: Derived variables
Variable Default 4 mA Default 20 mA
Base density 0.000 g/cm3 0.400 g/cm3
Calorific value 20 MJ/Nm3 60 MJ/Nm3
Wobbe index 20 MJ/Nm3 60 MJ/Nm3
Sample temperature -50.000°C
-58°F
200.000°C
392°F
Drive gain 0.000 % 100.000 %
External temperature -50.000°C
-58.00000°F
200.000°C
392.0000°F
Configuration and Use Manual Introduction to configuration and commissioning
MMI-20020954 March 2021
Configuration and Use Manual 23
