h) Activate Scroll until the desired character is displayed.
4. Enter the sign.
a) Activate Select to move the cursor one digit to the left.
b) Activate Scroll until the desired character is displayed.
For positive numbers, select a blank space.
5. To save the displayed value to transmitter memory, activate Scroll and Select simultaneously and hold
until the display changes.
• If the displayed value is the same as the value in transmitter memory, you will be returned to the
previous screen.
• If the displayed value is not the same as the value in transmitter memory, SAVE/YES? flashes on the
display. Activate Select.
6. Switch back from exponential notation to decimal notation.
a) Activate Select until the E is flashing.
b) Activate Select until d is displayed.
c) Activate Select.
B.4 Display codes for process variables
Table B-2: Display codes for process variables
Code Definition
Standard
DENS Line Density
TEMP Sample Temperature
EXT T Line Temperature (External)
EXT P Line Pressure (External)
Z Compressibility
MAG V Volume Flow Rate (External)
MAG M Mass Flow Rate (Calculated)
COR M Mass Flow Rate (External)
COR V Volume Flow Rate (Calculated)
DRIVE% Drive Gain
TP B Sensor Time Period
UCALC User-Defined Calculation Output
Concentration measurement
CONC Concentration
NET M Net Mass
