Option Description
The event occurs when the value of the assigned process variable (x) is less than
the setpoint (Setpoint A), endpoint not included.
IN A ≤ x ≤ B
The event occurs when the value of the assigned process variable (x) is in range,
that is, between Setpoint A and Setpoint B, endpoints included.
OUT x ≤ A or x ≥ B
The event occurs when the value of the assigned process variable (x) is out of
range, that is, less than Setpoint A or greater than Setpoint B, endpoints
included.
3. Assign a process variable to the event.
4. Set values for the required setpoints.
• For HI and LO events, set Setpoint A.
• For IN and OUT events, set Setpoint A and Setpoint B.
5. Optional: Configure a Discrete Output to switch states in response to the event status.
Related information
Configure Discrete Output Source
10.5 Configure HART/Bell 202 communications
HART/Bell 202 communications parameters support HART communications with the transmitter's primary
mA terminals over a HART/Bell 202 network.
10.5.1 Configure basic HART parameters
ProLink III
Device Tools → Configuration → Meter Information
Device Tools → Configuration → Communications → Communications (HART)
Field communicator Configure → Manual Setup → HART → Communications
Basic HART parameters include the HART address, HART tags, and the operation of the primary mA output.
Restriction
• Your device supports HART 7. If you are using HART 5, HART Long Tag is not available.
• HART Tag, HART Long Tag, and mA Output Action are not configurable from the display.
Procedure
1. Set HART Address to a unique value on your network.
Valid address values are between 0 and 15. The default address (0) is typically used unless you are in a
multidrop environment.
Integrate the meter with the control system Configuration and Use Manual
March 2021 MMI-20020954
94 Micro Motion Gas Specific Gravity Meters (SGM)
