Option Description Setup
Polling The meter polls an external
device for % N2 data.
a. Set % N2 Source to Poll for External Value.
b. Set Polling Slot to an available slot.
c. Set Polling Control to Poll as Primary or Poll as Secondary.
d. Set External Device Tag to the HART tag of the % N2
measurement device.
Digital
communications
A host writes % N2 data to the
meter at appropriate intervals.
a. Set % N2 Source to Fixed Value or Digital Communications.
b. Perform the necessary host programming and
communications setup to write % N2 data to the meter at
appropriate intervals.
Fixed value The configured fixed value is
used.
a. Set % N2 Source to Fixed Value or Digital Communications.
b. Set % N2 (Fixed) to the desired value, in % by volume.
8. If you set Compressibility Measurement Method to SGERG 88, set % H2 Source to the method you
will use to supply % H2 data, and perform the required setup.
Option Description Setup
Polling The meter polls an external
device for % H2 data.
a. Set % H2 Source to Poll for External Value.
b. Set Polling Slot to an available slot.
c. Set Polling Control to Poll as Primary or Poll as Secondary.
d. Set External Device Tag to the HART tag of the % H2
measurement device.
Digital
communications
A host writes % H2 data to the
meter at appropriate intervals.
a. Set % H2 Source to Fixed Value or Digital Communications.
b. Perform the necessary host programming and
communications setup to write % H2 data to the meter at
appropriate intervals.
Fixed value The configured fixed value is
used.
a. Set % H2 Source to Fixed Value or Digital Communications.
b. Set % H2 (Fixed) to the desired value, in % by volume.
