Options for mA Output Process Variable
The transmitter provides a basic set of options for mA Output Process Variable, plus several application-
specific options. Different communications tools may use different labels for the options.
Process variable Label
Display ProLink III Field communicator
Standard
Line Density DENS Line Density Density
Sample Temperature TEMP Sample Temperature Temperature
Line Temperature (External
or Fixed)
EXT T Line Temperature (External
or Fixed)
External Temperature
Line Pressure (External or
Fixed)
EXT P Line Pressure (External or
Fixed)
External Pressure
Volume Flow Rate (External) MAG V Volume Flow Rate (External) Volume from Mag/Vortex
Meter
Mass Flow Rate (Calculated) MAG M Mass Flow Rate (Calculated) Calculated Mass Flow from
Mag Meter Input
Mass Flow Rate (External) COR M Mass Flow Rate (External) Mass from Coriolis Meter
Volume Flow Rate
(Calculated)
COR V Volume Flow Rate
(Calculated)
Volume Flow at Reference
Temperature
Drive Gain DGAIN Drive Gain Drive Gain
Sensor Time Period TP B Sensor Time Period Sensor Time Period
User-Defined Calculation
Output
UCALC User-Defined Calculation
Output
User-Defined Calculation
Output
Concentration measurement
Concentration CONC Concentration Concentration (CM)
Net Mass Flow Rate NET M Net Mass Flow Rate Net Mass Flow Rate (CM)
Net Volume Flow Rate NET V Net Volume Flow Rate Net Volume Flow Rate (CM)
Gas measurement
Base Density BDENS Base Density (Gas) Base Density (Gas)
Specific Gravity SG Specific Gravity (Gas) Specific Gravity (Gas)
Relative Density RD Relative Density (Gas) Relative Density
Molecular Weight MW Molecular Weight (Gas) Molecular Weight
%CO
2
CO2 %CO2 Percent CO2
%H
2
N2 %H2 Percent H2
%N
2
H2 %N2 Percent N2
%CO CO %CO Percent CO
Energy measurement
Calorific Value CV Calorific Value Calorific Value
