Result: A change in specific gravity will be reflected in the mA output over a time period that is greater than
3 seconds. The exact time period is calculated by the transmitter according to internal algorithms which are
not configurable.
10.2.4 Configure mA Output Fault Action and mA Output Fault
Level
ProLink III Device Tools → Configuration → I/O → Outputs → mA Output → mA Output 1 → Fault Action
Device Tools → Configuration → I/O → Outputs → mA Output → mA Output 2 → Fault Action
Field communicator Configure → Manual Setup → Inputs/Outputs → mA Output 1 → mAO1 Fault Settings → MAO1 Fault
Action
Configure → Manual Setup → Inputs/Outputs → mA Output 2 → MAO2 Fault Settings → MAO2 Fault
Action
mA Output Fault Action controls the behavior of the mA output if the transmitter encounters an internal
fault condition.
Note
For some faults only: If Fault Timeout is set to a non-zero value, the transmitter will not implement the fault
action until the timeout has elapsed.
Procedure
1. Set mA Output Fault Action to the desired value.
The default setting is Downscale.
Restriction
If Digital Communications Fault Action is set to NAN (not a number), you cannot set mA Output Fault
Action to None. If you try to do this, the device will not accept the configuration.
2. If you set mA Output Fault Action to Upscale or Downscale, set mA Output Fault Level as desired.
Postrequisites
NOTICE
If you set mA Output Fault Action to None, be sure to set Digital Communications Fault Action to None. If
you do not, the output will not report actual process data, and this may result in measurement errors or
unintended consequences for your process.
Options for mA Output Fault Action and mA Output Fault Level
Option
mA Output behavior
mA Output Fault Level
Upscale Goes to the configured fault level Default: 21.5 mA
Range: 21.0 to 21.5 mA
Downscale (default) Goes to the configured fault level Default: 3.2 mA
Range: 3.2 to 3.6 mA
Integrate the meter with the control system Configuration and Use Manual
March 2021 MMI-20020954
90 Micro Motion Gas Specific Gravity Meters (SGM)
