Emerson ZX Platform Condensing Unit - ZXD Controller Assembly and Operation

ZX Platform Condensing Unit
18
12
Modulated Fan
3
Emerson Controller On ZXD
ZXD Controller Assembly
Program Mode: browses parameter codes or
increase value
Hot Key Insert : Hot key programming
procedure
INFO Menu: Press and release it to access
INFO Menu
Program Mode: below parameter codes or
decrease value
Maintenance /Clock
Suction pressure
Suction temperature display
Condenser pressure
Condenser temperature display
Enter Alarm
Manual Restart
Setup Menu
ure
e
rature
d
s
er press
u
1: Mid-Coil Temp Sensor
2: Suction Pressure Transducer
3: Discharge Temp Sensor
