ZX Platform Condensing Unit
34
ZX Family: Medium Temperature
Technical Data at 50 Hz - PFJ
Family ZX
Nominal Rating Horsepower HP 2 2.5 3 4
Model Name ZX0200 ZX0250 ZX0300 ZX0400
ZX020E ZX025E ZX030E ZX040E
Performance
R22 ET/AT/RGT °C
-6.7/32/18.3
Capacity kW 3.85 4.58 5.5 7.3
COP W/W
2.41 2.18 2.5 2.52
R404A/R507A ET/AT/RGT °C
-6.7/32/18.3
Capacity kW 4.30 5.05 6.00 7.80
COP W/W
2.26 2.05 2.35 2.29
Sound Pressure Level @1m dB(A) 60
Compressor Model Name
R22
R404A/R507A
ZX15KC-PFJ ZX19KC-PFJ ZX21KC-PFJ ZX29KC-PFJ
ZX15KCE-PFJ ZX19KCE-PFJ ZX21KCE-PFJ ZX29KCE-PFJ
Rated Load Ampere R22 Amp
R404A/R507A
13.2 14.6 16.4 20.0
13.2 14.6 16.4 20.0
Locked Rotor Ampere
R22 Amp
R404A/R507A
58.0 61.0 82.0 114.0
58.0 61.0 82.0 114.0
Oil Type R22
R404A/R507A
MINERAL
POE
Oil Recharge Volume R22/R404A /R507A Liters 1.18 1.33 1.33 1.83
Fan Motor Number of Fan Pieces 1 1 1 1
Diameter mm 450 450 450 450
Fan Speed rpm 933 933 933 933
Air Flow Total m3/h 3483 3483 3483 3483
Total Fan Motor Power Input W 116 116 116 116
Others Oil Separator Volume Liters 0.5
Receiver Volume R22 kg
R404A/R507A kg
5.1 5.1 5.1 5.1
4.4 4.4 4.4 4.4
Pipes Suction OD Inch
Liquid OD Inch
3/4 3/4 3/4 3/4
1/2 1/2 1/2 1/2
Dimension W x D x H mm 1029X424X840
Weight Net kg
Gross kg
76 79 79 100
114 117 117 138
