ZX Platform Condensing Unit
36
ZX Family: Medium Temperature
Technical Data at 60 Hz - TF5/TF7
Family ZX
Nominal Rating Horsepower HP 2 3 4 5 6 7.5
Model Name
ZX0200 ZX0300 ZX0400 ZX0500 ZX0600 ZX0750
ZX020E ZX030E ZX040E ZX050E ZX060E ZX075E
Performance
R22 ET/AT/RGT °C
-7/32/18.3
Capacity kW
COP W/W
4.6 6.49 9.52 10.76 12.77 14.18
2.42 2.37 2.56 2.51 2.45 2.37
R404A/R507A ET/AT/RGT °C
-7/32/18.3
Capacity kW
COP W/W
5.10 7.30 10.16 12.46 14.48 15.28
2.37 2.27 2.48 2.43 2.42 2.22
Sound Pressure Level @1m dB(A) 60
Compressor
Model Name R22
R404A/R507A
ZX15KC-TF5/TF7 ZX21KC-TF5/TF7 ZX29KC-TF5/TF7 ZX38KC-TF5/TF7 ZX45KC-TF5/TF7 ZX51KC-TF5/TF7
ZX15KCE-TF5/TF7 ZX21KCE-TF5/TF7 ZX29KCE-TF5/TF7 ZX38KCE-TF5/TF7 ZX45KCE-TF5/TF7 ZX51KCE-TF5/TF7
Rated Load Ampere R22 Amp
R404A/R507A Amp
8.9/5 11.4/7.5 15/9.3 20.7/10.7 20.7/10.7 25/12.1
8.9/5.1 12.1/7.4 15.7/9.6 24/12.4 23.1/12.6 26/14.1
Locked Rotor Ampere R22 Amp
R404A/R507A Amp
55/27 77/39 115/54 128/64 156/70 164/100
55/27 77/39 115/54 128/64 156/70 164/100
Oil Type R22
R404A/R507A
MINERAL
POE
Oil Recharge Volume R22/R404A Liters
/R507A
1.18 1.33 1.83 1.83 1.66 1.66
Fan Motor
Number of Fan Pieces 1 1 2 2 2 2
Diameter mm 450 450 450 450 450 450
Fan Speed rpm 933 933 933 933 933 933
Air Flow Total m3/h 3483 3483 6966 6966 6966 6966
Total Fan Motor Power Input W 145 145 290 290 290 290
Others
Oil Separator Volume Liters 0.5 0.5 0.5 0.5 0.5 0.5
Receiver Volume R22 kg
R404A/R507A kg
5.1 5.1 7.2 7.2 7.2 7.2
4.4 4.4 6.3 6.3 6.3 6.3
Pipes Suction OD Inch
Liquid OD Inch
3/4 3/4 3/4 3/4 3/4 3/4
1/2 1/2 1/2 1/2 1/2 1/2
Dimension W x D x H mm 1029X424X840 1029X424X1242
Weight Net kg
Gross kg
76 79 100 108 112 121
113.5 116.5 135 152 156 162
