ZXL Family: Low Temperature
Technical Data at 50 Hz - TFD
Family ZX
Nominal Rating Horsepower HP 2 2.5 3 3.5 4 5 6 7.5
Model Name
ZXL0200 ZXL0250 ZXL0300 ZXL0350 ZXL0400 ZXL0500 ZXL0600 ZXL0750
ZXL020E ZXL025E ZXL030E ZXL035E ZXL040E ZXL050E ZXL060E ZXL075E
Performance
R22 ET/AT/RGT °C
-32/32/5°C
Capacity kW
1.7 1.91 2.34 2.78 3.57 4.05 4.96 5.39
COP W/W 1.2 1.17 1.28 1.26 1.24 1.29 1.27 1.28
R404A/R507A ET/AT/RGT °C
-32/32/5°C
Capacity kW
2.11 2.51 2.80 3.65 4.26 4.99 5.91 6.65
COP W/W 1.24 1.28 1.29 1.34 1.29 1.36 1.33 1.38
Sound Pressure Level @1m dB(A) 60 61
Compressor
Model Name R22
R404A/R507A
ZXI06KC-TFD ZXI08KC-TFD ZXI09KC-TFD ZXI11KC-TFD ZXI14KC-TFD ZXI15KC-TFD ZXI18KC-TFD ZXI21KC-TFD
ZXI06KCE-TFD ZXI08KCE-TFD ZXI09KCE-TFD ZXI11KCE-TFD ZXI14KCE-TFD ZXI15KCE-TFD ZXI18KCE-TFD ZXI21KCE-TFD
Rated Load Ampere R22 Amp
R404A/R507A Amp
5.4 5.5 5.7 7.4 8.1 8.8 11.1 12.1
5.6 6.2 6.0 8.3 8.6 10.0 11.1 14.6
Locked Rotor Ampere R22 Amp
R404A/R507A Amp
39.2 39.2 39.2 51.5 51.5 51.5 74.0 101.0
39.2 39.2 39.2 51.5 51.5 51.5 74.0 101.0
Oil Type R22
R404A/R507A
MINERAL
POE
Oil Recharge Volume R22/R404A Liters
/R507A
0.56 0.56 0.56 1.24 1.24 1.24 1.77 1.77
Fan Motor
Number of Fan Pieces 1 1 1 1 1 2 2 2
Diameter mm 450 450 450 450 450 450 450 450
Fan Speed rpm 830 830 830 830 830 830 830 830
Air Flow Total m3/h 2922 2922 2922 2922 2922 5910 5910 5910
Total Fan Motor Power Input W 116 116 116 116 116 246 246 246
Others
Oil Separator Volume Liters 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
Receiver Volume R22 kg
R404A/R507A kg
5.1 5.1 5.1 5.1 5.1 7.2 7.2 7.2
4.4 4.4 4.4 4.4 4.4 6.3 6.3 6.3
Pipes Suction OD Inch
Liquid OD Inch
3/4 3/4 3/4 7/8 7/8 7/8 7/8 7/8
1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
Dimension W x D x H mm 1029X424X840 1029X424X1242
Weight Net kg
Gross kg
79 81 81 93 93 106 116 121
117 119 119 131 131 150 165 170
