Emerson ZX Platform Condensing Unit - ZXL Family: Low Temperature at 60 Hz - TF5;TF7

ZX Platform Condensing Unit
40
ZXL Family: Low Temperature
Technical Data at 60 Hz - TF5/TF7
Family ZX
Nominal Rating Horsepower HP 2 2.5 3 3.5 4 5 6 7.5
Model Name
ZXL0200 ZXL0250 ZXL0300 ZXL0350 ZXL0400 ZXL0500 ZXL0600 ZXL0750
ZXL020E ZXL025E ZXL030E ZXL035E ZXL040E ZXL050E ZXL060E ZXL075E
Performance
R22 ET/AT/RGT °C
-32/32/5°C
Capacity kW
2.09 2.69 2.99 2.59 4.72 5.32 6.34 6.81
COP W/W 1.14 1.18 1.28 1.31 1.36 1.37 1.27 1.24
R404A/R507A ET/AT/RGT °C
-32/32/5°C
Capacity kW
2.41 2.83 3.54 4.19 5.18 6.26 7.52 7.98
COP W/W 1.12 1.15 1.32 1.33 1.33 1.44 1.29 1.32
Sound Pressure Level @1m dB(A) 60 61
Compressor
Model Name R22
R404A/R507A
ZXI06KC-TF5/7 ZXI08KC-TF5/7 ZXI09KC-TF5/7 ZXI11KC-TF5/7 ZXI14KC-TF5/7 ZXI15KC-TF5/7 ZXI18KC-TF5/7 ZXI21KC-TF5/7
ZXI06KCE-TF5/7 ZXI08KCE-TF5/7 ZXI09KCE-TF5/7 ZXI11KCE-TF5/7 ZXI14KCE-TF5/7 ZXI15KCE-TF5/7 ZXI18KCE-TF5/7 ZXI21KCE-TF5/7
Rated Load Ampere R22 Amp
TF5 R404A/R507A Amp
12.1 12.6 12.9 19.1 20 21.4 25.5 28.9
12.1 12.6 12.9 19.1 20 21.4 25.5 28.9
Rated Load Ampere R22 Amp
TF7 R404A/R507A Amp
5.4 5.5 6.9 7.7 9.9 12.6 14.1 14.4
5.6 6.2 6.9 8.6 9.9 12.6 14.1 14.4
Locked Rotor Ampere R22 Amp
R404A/R507A Amp
73.0 73.0 73.0 110.0 110.0 110.0 186.6 191.0
34.8 34.8 38.6 47.0 66.0 73.5 94.3 94.3
Oil Type R22
R404A/R507A
MINERAL
POE
Oil Recharge Volume R22/R404A Liters
/R507A
0.56 0.56 0.56 1.24 1.24 1.24 1.77 1.77
Fan Motor
Number of Fan Pieces 1 1 1 1 2 2 2 2
Diameter mm 450 450 450 450 450 450 450 450
Fan Speed rpm 933 933 933 933 933 933 933 933
Air Flow Total m3/h 3483 3483 3483 3483 6966 6966 6966 6966
Total Fan Motor Power Input W 145 145 145 145 290 290 290 290
Others
Oil Separator Volume Liters 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
Receiver Volume R22 kg
R404A/R507A kg
5.1 5.1 5.1 5.1 5.1 5.1 5.1 5.1
4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4
Pipes Suction OD Inch
Liquid OD Inch
3/4 3/4 3/4 7/8 7/8 7/8 7/8 7/8
1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
Dimension W x D x H mm 1029X424X840 1029X424X1242
Weight Net kg
Gross kg
79 81 81 93 93 106 116 121
117 119 119 131 143 150 165 170
