ZX Family: Medium Temperature
Technical Data at 50 Hz - TFD
Family ZX
Nominal Rating Horsepower HP 2 3 4 5 6 7.5 7.6
Model Name
ZX0200 ZX0300 ZX0400 ZX0500 ZX0600 ZX0750 ZX0760
ZX020E ZX030E ZX040E ZX050E ZX060E ZX075E ZX076E
Performance
R22 ET/AT/RGT °C
-6.7/32/18.3
Capacity kW
COP W/W
3.85 5.50 7.30 9.30 11.20 12.60 12.85
2.41 2.50 2.52 2.66 2.60 2.57 2.65
R404A/R507A ET/AT/RGT °C
-6.7/32/18.3
Capacity kW
COP W/W
4.30 6.00 7.80 10.70 11.80 13.20 13.46
2.26 2.35 2.29 2.43 2.41 2.40 2.50
Sound Pressure Level @1m dB(A) 60
Compressor
Model Name R22
R404A/R507A
ZX15KC-TFD ZX21KC-TFD ZX30KC-TFD ZX38KC-TFD ZX45KC-TFD ZX51KC-TFD ZX51KC-TFD
ZX15KCE-TFD ZX21KCE-TFD ZX30KCE-TFD ZX38KCE-TFD ZX45KCE-TFD ZX51KCE-TFD ZX51KCE-TFD
Rated Load Ampere
R22 Amp
R404A/R507A Amp
4.3 5.7 7.4 8.9 11.5 12.0 12.0
5.0 6.1 7.5 9.6 11.5 11.8 11.8
Locked Rotor Ampere R22 Amp
R404A/R507A Amp
26.0 36.0 44.3 58.6 67.0 101.0 101.0
26.0 36.0 44.3 58.6 67.0 101.0 101.0
Oil Type R22
R404A/R507A
MINERAL
POE
Oil Recharge Volume
R22/R404A Liters
/ R507A
1.18 1.33 1.83 1.83 1.66 1.66 1.66
Fan Motor
Number of Fan Pieces
1 1 1 2 2 2 2
Diameter mm
450 450 450 450 450 450 450
Fan Speed rpm 830 830 830 830 830 830 830
Air Flow Total m3/h 2922 2922 2922 5910 5910 5910 5910
Total Fan Motor Power Input W 116 116 116 246 246 246 246
Others
Oil Separator Volume Liters 0.5 0.5 0.5 0.5 0.5 0.5 0.5
Receiver Volume R22 kg
R404A/R507A kg
5.1 5.1 5.1 7.2 7.2 7.2 7.2
4.4 4.4 4.4 6.3 6.3 6.3 6.3
Pipes Suction OD Inch
Liquid OD Inch
3/4 3/4 7/8 7/8 7/8 7/8 7/8
1/2 1/2 1/2 1/2 1/2 1/2 1/2
Dimension W x D x H mm 1029X424X840 1029X424X1242
Weight Net kg
Gross kg
76 79 91 108 112 118 121
113.5 116.5 121 152 156 162 154
