ZX Platform Condensing Unit
38
ZXD Family: Digital Medium Temperature
Technical Data at 60 Hz - TF7
Family ZX
Nominal Rating Horsepower HP 4 5 6 7.5
Model Name
ZXD040E ZXD050E ZXD060E ZXD075E
Performance
R22 ET/AT/RGT °C n/a n/a n/a n/a
Capacity kW
COP W/W
n/a n/a n/a n/a
n/a n/a n/a n/a
R404A/R507A ET/AT/RGT °C
-10/32/18.3
Capacity kW
8.70 10.77 12.54 13.84
COP W/W 2.18 2.11 2.12 2.08
Sound Pressure Level @1m dB(A) 60
Compressor
Model Name R22
R404A/R507A
n/a n/a n/a n/a
ZBD29KQE-TF7 ZBD38KQE-TF7 ZBD45KQE-TF7 ZBD48KQE-TF7
Rated Load Ampere R22 Amp
R404A/R507A Amp
n/a n/a n/a n/a
9.6 11.6 12.9 14.6
Locked Rotor Ampere R22 Amp
R404A/R507A Amp
n/a n/a n/a n/a
54.0 64.0 70.0 78.0
Oil Type R22
R404A/R507A
n/a
POE 3MAF
Oil Recharge Volume R22/R404A Liters
/R507A
1.24 1.77 1.77 1.77
Fan Motor
Number of Fan Pieces 2 2 2 2
Diameter mm 450 450 450 450
Fan Speed rpm 933 933 933 933
Air Flow Total m3/h 6966 6966 6966 6966
Total Fan Motor Power Input W 290 290 290 290
Others
Oil Separator Volume Liters 0.5 0.5 0.5 0.5
Receiver Volume R22 kg
R404A/R507A kg
n/a n/a n/a n/a
6.3 6.3 6.3 6.3
Pipes Suction OD Inch
Liquid OD Inch
7/8 7/8 7/8 7/8
1/2 1/2 1/2 1/2
Dimension W x D x H mm 1029X424X1242
Weight Net kg
Gross kg
109 117 121 127
148 156 158 163
