Emerson ZX Platform Condensing Unit - 60 Hz

27
ZX Family: Medium Temperature
Capacity and Power (kW) at 60 Hz - TF5/TF7
R404A/R507 - 60 Hz
Model
Ambient
Temperature
(
o
C)
Capacity
Evaporating Temperature (
o
C)
Power
Evaporating Temperature (
o
C)
-20 -15 -10 -5 0 5 -20 -15 -10 -5 0 5
ZX020E
27 3.50 4.26 4.98 5.77 6.71 7.89 1.84 1.87 1.90 1.95 2.00 2.05
32 3.15 3.94 4.66 5.40 6.25 7.30 2.09 2.10 2.12 2.16 2.20 2.24
38 2.69 3.52 4.24 4.93 5.69 6.60 2.42 2.42 2.44 2.47 2.50 2.54
43 2.22 3.09 3.82 4.48 5.17 5.97 2.71 2.71 2.73 2.76 2.81 2.85
ZX030E
27 5.02 5.98 7.05 8.17 9.29 10.36 2.69 2.80 2.92 3.05 3.17 3.29
32 4.62 5.56 6.63 7.75 8.88 9.97 2.98 3.06 3.16 3.26 3.36 3.45
38 4.14 5.02 6.02 7.10 8.18 9.23 3.38 3.46 3.55 3.65 3.75 3.85
43 3.78 4.56 5.47 6.46 7.47 8.44 3.74 3.84 3.95 4.08 4.21 4.33
ZX040E
27 6.71 8.02 9.60 11.30 13.00 14.59
3.72 3.79 3.89 3.99 4.10 4.18
32 6.46 7.70 9.20 10.81 12.42 13.90
3.84 3.92 4.02 4.14 4.26 4.35
38 5.90 7.05 8.45 9.95 11.43 12.76 4.32 4.40 4.50 4.62 4.74 4.84
43 5.36 6.43 7.73 9.12 10.49 11.69 4.89 4.95 5.05 5.16 5.27 5.37
ZX050E
27 8.10 9.70 11.55 13.54 15.53 17.38 4.42 4.63 4.86 5.11 5.35 5.57
32 8.05 9.56 11.33 13.21 15.09 16.83 4.59 4.78 4.99 5.22 5.45 5.66
38 7.46 8.86 10.50 12.25 13.99 15.58 5.10 5.27 5.48 5.70 5.93 6.13
43 6.81 8.10 9.63 11.26 12.88 14.33 5.62 5.80 6.01 6.24 6.47 6.69
ZX060E
27 9.84 11.77 13.96 16.31 18.74 21.15 5.06 5.24 5.49 5.76 6.01 6.20
32 9.25 11.09 13.16 15.36 17.60 19.79 5.39 5.58 5.82 6.09 6.35 6.55
38 8.30 10.09 12.06 14.13 16.19 18.16 6.09 6.25 6.48 6.74 6.99 7.19
43 7.32 9.11 11.04 13.03 14.98 16.82 6.82 6.96 7.17 7.41 7.65 7.83
ZX075E
27 11.16 13.39 14.92 17.64 19.93 22.58 4.80 5.00 5.69 6.06 6.54 6.96
32 10.29 12.35 13.84 16.23 18.18 21.23 5.74 5.92 6.66 7.00 7.46 7.87
38 9.01 10.78 12.43 14.60 16.31 18.99 6.42 6.60 7.35 7.66 8.09 8.45
43 7.73 9.79 11.25 13.33 14.95 17.39 7.28 7.43 8.20 8.48 8.87 9.19
Notes: Power includes condenser fan.
Ambient 38°C and 43°C are typical design conditions for unit selection.
