Emerson ZX Platform Condensing Unit User Manual

25
Model
Ambient
Temperature
(
o
C)
Capacity
Evaporating Temperature (
o
C)
Power
Evaporating Temperature (
o
C)
-15
-10
-5 0 5 -15 -10 -5 0 5
ZX0200
27 3.62 4.42 5.36 6.43 7.59 1.69 1.71 1.69 1.69 1.71
32 3.41 4.22 5.17 6.20 7.29 1.89 1.91 1.90 1.89 1.90
38 2.88 3.77 4.75 5.78 6.84 2.13 2.17 2.17 2.17 2.18
43 2.20 3.19 4.24 5.31 6.38 2.35 2.41 2.42 2.43 2.45
48 1.30 2.43 3.58 4.73 5.84 2.59 2.67 2.71 2.73 2.75
50 0.88 2.07 3.27 4.46 5.60 2.69 2.78 2.83 2.85 2.89
ZX0300
27 5.12 6.20 7.29 8.90 10.54 2.42 2.53 2.69 2.73 2.77
32 4.91 5.84 6.98 8.48 10.00 2.60 2.73 2.88 2.90 3.05
38 4.39 5.51 6.53 7.96 9.38 2.94 3.08 3.21 3.22 3.42
43 3.90 5.03 5.94 7.35 8.74 3.27 3.41 3.52 3.65 3.77
48 2.86 4.23 5.01 6.45 7.86 3.70 3.94 4.07 4.15 4.34
50 2.45 3.12 4.51 5.98 7.40 3.86 4.16 4.29 4.36 4.57
ZX0400
27 7.36 8.83 10.52 12.37 14.31 3.25 3.35 3.52 3.75 4.02
32 7.06 8.54 10.21 12.02 13.92 3.55 3.63 3.79 4.01 4.28
38 6.37 7.87 9.55 11.34 13.20 4.05 4.11 4.26 4.48 4.75
43 5.62 7.16 8.86 10.66 12.50 4.55 4.60 4.73 4.95 5.22
48 4.82 6.41 8.14 9.96 11.81 5.09 5.12 5.25 5.46 5.74
50 4.50 6.12 7.87 9.70 11.55 5.30 5.33 5.46 5.67 5.95
ZX0500
27 8.55 10.51 12.53 14.66 16.95 3.54 3.72 3.91 4.05 4.27
32 8.12 9.97 11.95 14.06 16.42 4.15 4.13 4.39 4.52 4.88
38 7.49 9.23 11.14 13.28 15.68 4.64 4.76 5.00 5.25 5.49
43 6.53 8.16 10.03 12.18 14.65 5.25 5.25 5.49 5.74 6.10
48 4.75 6.96 9.14 11.39 13.76 6.33 6.40 6.69 6.90 7.13
50 4.04 6.48 8.79 11.07 13.41 6.76 6.87 7.16 7.37 7.55
ZX0600
27 10.20 12.49 14.99 17.66 21.19 4.39 4.62 4.85 5.20 5.54
32 9.25 11.92 14.05 16.73 19.56 4.85 5.08 5.31 5.54 5.89
38 8.17 10.10 12.68 15.42 18.31 5.43 5.66 5.89 6.12 6.35
43 7.09 8.68 11.28 14.14 17.11 6.12 6.47 6.81 7.04 7.16
48 5.96 8.40 11.10 13.38 15.70 7.53 7.77 8.07 8.37 8.70
50 5.51 8.29 11.03 13.08 15.13 8.09 8.16 8.44 8.75 9.00
ZX0750
27 11.25 14.06 16.61 19.89 24.05 5.10 5.34 5.59 5.86 6.14
32 10.60 12.95 16.02 19.16 23.29 5.60 5.82 6.11 6.48 6.95
38 9.91 12.51 15.28 17.85 22.38 6.31 6.51 6.86 7.35 8.00
43 9.18 11.53 14.17 16.50 21.31 7.00
7.17 7.56 8.15 8.96
48 7.96 9.66 12.95 15.92 19.74 8.15 8.45 8.88 9.47 10.12
50 7.48 8.92 12.46 15.69 19.11 8.61 8.96 9.41 10.00 10.58
Note: Power include condenser fan.
Ambient 38°C and 43°C are typical design conditions for unit selection.
ZX Family: Medium Temperature
Capacity and Power (kW) at 60 Hz - TF5/TF7
R22 - 60 Hz
