Emerson ZX Platform Condensing Unit - Capacity and Power (Kw); ZX Family: Medium Temperature - R22; 50 Hz

ZX Platform Condensing Unit
24
ZX Family: Medium Temperature
Capacity and Power (kW) at 50 Hz - PFJ/TFD
R22 - 50 Hz
Model
Ambient
Temperature
(
o
C)
Capacity
Evaporating Temperature (
o
C)
Power
Evaporating Temperature (
o
C)
-15 -10 -5 0 5 10 12 -15 -10 -5 0 5 10 12
ZX0200
27 2.84 3.61 4.18 4.95 5.87 7.03 7.45 1.33 1.37 1.41 1.47 1.53 1.70 1.79
32 2.65 3.33 4.01 4.75 5.61 6.54 6.96 1.45 1.50 1.58 1.64 1.71 1.84 1.88
38 2.38 3.11 3.81 4.55 5.37 6.19 6.68 1.62 1.74 1.83 1.87 1.91 2.03 2.08
43 1.93 2.74 3.48 4.23 5.06 5.99 6.33 1.78 1.83 1.95 2.05 2.11 2.20 2.25
48 1.68 2.30 3.18 3.87 4.69 5.51 5.80 2.21 2.31 2.44 2.51 2.54 2.55 2.64
ZX0250
1
27 2.72 3.64 4.39 5.09 5.83 6.71 8.36 1.79 1.90 1.94 1.95 1.95 1.98 2.12
32 2.56 3.45 4.18 4.83 5.52 6.33 7.87 2.02 2.14 2.18 2.19 2.19 2.21 2.34
38 2.11 3.00 3.71 4.33 4.98 5.74 7.18 2.35 2.47 2.51 2.51 2.51 2.52 2.64
43 1.62 2.53 3.25 3.88 4.51 5.25 6.64 2.67 2.78 2.83 2.83 2.82 2.83 2.93
48 2.08 2.83 3.48 4.13 4.86 7.37 6.23 3.15 3.19 3.18 3.17 3.17 2.29 3.25
ZX0300
27 4.30 5.20 6.28 7.57 9.09 10.22 10.80 1.95 2.04 2.17 2.20 2.23 2.43 2.49
32 4.12 4.90 5.95 7.28 8.69 9.79 10.31 2.10 2.20 2.32 2.34 2.46 2.70 2.77
38 3.68 4.62 5.65 6.85 8.29 9.06 9.63 2.37 2.48 2.59 2.60 2.76 3.06 3.12
43 3.27 4.22 5.27 6.50 7.97 8.63 9.08 2.64 2.75 2.84 2.94 3.04 3.32 3.36
48 2.40 3.55 4.65 5.67 6.86 7.97 8.50 2.98 3.18 3.28 3.35 3.50 3.64 3.69
ZX0400
27 5.98 7.20 8.57 10.03 11.54 13.82 14.64 2.64 2.71 2.83 2.98 3.08 3.34 3.36
32 5.46 6.73 8.13 9.62 11.16 13.01 13.85 2.81 2.90 3.06 3.19 3.33 3.68 3.68
38 4.72 6.01 7.42 8.93 10.48 12.09 13.04 3.08 3.27 3.39 3.49 3.65 4.09 4.07
43 4.09 5.37 6.78 8.27 9.80 11.61 12.25 3.29 3.52 3.68 3.80 3.95 4.38 4.39
48 3.55 4.50 6.20 7.57 9.08 10.68 11.23 4.16 4.46 4.49 4.72 4.80 5.07 5.18
ZX0500
2
27 7.13 8.76 10.44 12.22 14.12 17.28 18.22 2.88 3.03 3.18 3.29 3.47 4.16 4.28
32 6.77 8.31 9.96 11.72 13.68 16.62 17.47 3.37 3.35 3.57 3.67 3.97 4.50 4.58
38 6.24 7.69 9.28 11.06 13.06 15.31 16.34 3.77 3.87 4.07 4.27 4.47 4.98 5.10
43 5.44 6.80 8.36 10.15 12.21 14.60 15.47 4.27 4.27 4.47 4.66 4.96 5.46
5.56
48 3.96 5.80 7.62 9.49 11.47 13.49 14.40 5.14 5.21 5.44 5.61 5.80 6.01 6.04
ZX0600
2
27 8.50 10.41 12.49 14.72 17.66 19.64 20.60 3.51 3.70 3.88 4.16 4.43 4.98 5.32
32 7.71 9.93 11.71 13.94 16.30 18.87 20.10 3.88 4.07 4.25 4.43 4.71 5.29 5.47
38 6.81 8.42 10.57 12.85 15.26 17.77 18.92 4.34 4.53 4.71 4.90 5.08 5.86 5.98
43 5.91 7.23 9.40 11.78 14.26 16.33 17.86 4.90 5.17 5.45 5.64 5.73 6.57 6.66
48 4.97 7.00 9.25 11.15 13.08 15.09 16.06 6.02 6.22 6.46 6.69 6.96 7.22 7.45
ZX0750
2
27 10.03 12.20 14.41 17.23 20.87 4.34 4.54 4.76 4.98 5.22
32 9.45 11.24 13.90 16.63 20.21 4.77 4.95 5.19 5.51 5.91
38 8.83 10.85 13.25 15.50 19.42 5.36 5.53 5.83 6.25 6.80
43 8.18 10.00 12.29 14.30 18.49 5.95 6.10 6.43 6.93 7.62
ZX0760
2
27 10.23 12.44 14.70 17.60 21.29 25.49 27.01 4.25 4.45 4.66 4.88 5.12 5.47 5.64
32 9.64 11.46 14.18 16.96 20.61 24.03 25.58 4.67 4.85 5.09 5.40 5.79 5.86 5.97
38 9.01 11.07 13.52 15.80 19.81 22.85 24.65 5.26 5.42 5.72 6.12 6.67 6.64 6.81
43 8.34 10.20 12.54 14.60 18.86 22.34 23.57 5.83 5.98 6.30 6.79 7.47 7.34 7.48
48 7.24 8.55 11.46 14.09 17.47 20.55 21.61 6.79 7.04 7.40 7.89 8.43 8.74 8.78
Notes:
1
Available on PFJ models only
2
Available on TFD models only
Based on a return gas temperature of 18.3°C.
Power includes condenser fan.
Ambient 38°C and 43°C are typical design conditions for unit selection.
