31
ZXL Family: Low Temperature
Capacity and Power (kW) at 60 Hz - TF5/ TF7
R22 - 60 Hz
Model
Ambient
Temperature
(
o
C)
Capacity
Evaporating Temperature (
o
C)
Power
Evaporating Temperature (
o
C)
-40 -35 -30 -25 -20 -15 -10 -5 0 -40 -35 -30 -25 -20 -15 -10 -5 0
ZXL0200
20 1.51 1.95 2.44 3.02 3.69 4.48 5.41 6.50 7.76 1.40 1.46 1.51 1.56 1.61 1.66 1.71 1.77 1.84
32 1.28 1.78 2.30 2.86 3.49 4.19 5.00 5.92 6.99 1.74 1.80 1.86 1.92 1.98 2.05 2.12 2.20 2.30
38 1.21 1.74 2.28 2.84 3.44 4.11 4.85 5.70 6.67 1.95 2.01 2.07 2.14 2.21 2.29 2.37 2.47 2.58
43 1.11 1.67 2.22 2.78 3.36 4.00 2.17 2.23 2.30 2.37 2.45 2.54
48 0.92 1.51 2.07 2.63 3.20 3.81 2.45 2.52 2.59 2.67 2.76 2.85
ZXL0250
20 2.37 2.52 2.93 3.56 4.37 5.33 6.41 7.56 8.77 1.85 1.89 1.91 1.98 1.99 2.02 2.07 2.14 2.23
32 2.36 2.48 2.82 3.38 4.11 4.99 5.97 7.03 8.13 2.23 2.25 2.29 2.33 2.40 2.48 2.58 2.70 2.84
38 2.34 2.46 2.75 3.26 3.93 4.75 5.67 6.67 7.70 2.62 2.65 2.68 2.73 2.80 2.88 2.98 3.10 3.25
43 2.38 2.50 2.71 3.16 3.78 4.54 3.01 3.02 3.05 3.09 3.14 3.21
48 2.39 2.51 2.69 3.08 3.64 4.34 3.38 3.39 3.39 3.41 3.44 3.49
ZXL0300
20 2.70 2.87 3.34 4.06 4.98 6.08 7.31 8.62 9.99 1.92 1.97 1.99 2.06 2.07 2.10 2.15 2.22 2.32
32 2.69 2.83 3.22 3.85 4.69 5.69 6.81 8.02 9.27 2.32 2.34 2.38 2.43 2.49 2.58 2.68 2.80 2.95
38 2.67 2.81 3.14 3.71 4.48 5.42 6.47 7.60 8.78 2.73 2.75 2.79 2.84 2.91 2.99 3.10 3.23 3.38
43 2.71 2.85 3.09 3.60 4.31 5.18 3.13 3.14 3.17 3.21 3.27 3.34
48 2.72 2.86 3.07 3.52 4.15 4.95 3.52 3.52 3.53 3.54 3.58 3.63
ZXL0350
20 3.26 3.48 4.04 4.91 6.03 7.36 8.84 10.43 12.09 2.25 2.30 2.32 2.41 2.42 2.46 2.52 2.60 2.72
32 3.26 3.42 3.90 4.66 5.67 6.88 8.24 9.70 11.22 2.71 2.74 2.78 2.84 2.92 3.01 3.14 3.28 3.46
38 3.23 3.40 3.80 4.49 5.43 6.55 7.83 9.20 10.62 3.19 3.22 3.26 3.33 3.40 3.50 3.63 3.78 3.95
43 3.28 3.45 3.74 4.36 5.22 6.27 3.66 3.68 3.71 3.76 3.82 3.91
48 3.30 3.46 3.72 4.25 5.03 5.98 4.11 4.12 4.13 4.15 4.19 4.25
ZXL0400
20 4.57 4.88 5.55 6.54 7.83 9.39 11.19 13.21 15.43 2.84 2.87 2.96 3.06 3.14 3.19 3.17 3.06 2.83
32 3.61 4.21 5.07 6.17 7.48 8.97
10.62 12.41 14.29 3.25 3.38 3.55 3.72 3.88 3.98 4.01 3.93 3.72
38 3.36 4.02 4.90 5.98 7.22 8.60 10.10 11.68 13.33 3.71 3.88 4.07 4.27 4.45 4.57 4.60 4.53 4.33
43 3.16 3.83 4.69 5.70 6.85 8.10 4.17 4.36 4.58 4.80 4.98 5.11
48 2.88 3.53 4.33 5.25 6.27 7.35 4.68 4.89 5.13 5.35 5.54 5.67
ZXL0500
20 4.80 6.02 6.84 7.99 9.47 11.27 13.38 15.79 18.50 2.77 2.97 3.19 3.41 3.60 3.73 3.79 3.74 3.56
32 3.90 4.71 5.73 6.97 8.42 10.06 11.88 13.88 16.04 3.57 3.76 3.98 4.21 4.42 4.58 4.67 4.67 4.55
38 3.73 4.62 5.67 6.86 8.20 9.66 11.25 12.95 14.76 4.01 4.22 4.47 4.73 4.97 5.17 5.31 5.36 5.29
43 3.64 4.55 5.56 6.67 7.87 9.15 4.47 4.71 5.00 5.29 5.58 5.83
48 3.38 4.27 5.22 6.20 7.22 8.27 5.07 5.36 5.69 6.04 6.38 6.69
ZXL0600
20 5.71 7.17 8.14 9.51 11.27 13.41 15.92 18.79 22.02 3.58 3.83 4.12 4.40 4.64 4.82 4.89 4.83 4.60
32 4.64 5.60 6.82 8.30 10.02 11.97 14.13 16.51 19.09 4.60 4.85 5.14 5.43 5.70 5.91 6.03 6.03 5.87
38 4.44 5.50 6.75 8.17 9.76 11.50 13.39 15.41 17.56 5.17 5.44 5.76 6.10 6.41 6.67 6.85 6.91 6.83
43 4.33 5.41 6.62 7.94 9.37 10.89 5.76 6.08 6.45 6.83 7.20 7.52
48 4.03 5.09 6.21 7.38 8.60 9.84 6.54 6.91 7.34 7.79 8.23 8.62
ZXL0750
20 6.05 7.60 8.62 10.08 11.94 14.21 16.88 19.92 23.34 3.93 4.22 4.53 4.84 5.11 5.30 5.38 5.31 5.06
32 4.91 5.93 7.23 8.80 10.62 12.68 14.98 17.50 20.23 5.06 5.34 5.65 5.97 6.27 6.50 6.63 6.63 6.46
38 4.71 5.83 7.15 8.66 10.34 12.19 14.19 16.34 18.61 5.68 5.99 6.34 6.71 7.05 7.34 7.54 7.60 7.51
43 4.59 5.74 7.02 8.42 9.93 11.54 6.34 6.69 7.09 7.51 7.92 8.27
48 4.27 5.39 6.58 7.82 9.11 10.43 7.19 7.60 8.07 8.57 9.05 9.49
Notes: Based on a return gas temperature of 5°C.
Power includes condenser fan.
Ambient 38°C and 43°C are typical design conditions for unit selection.
