ZX Platform Condensing Unit
48
PRESSURE TEMPERATURE CHART AT SEA LEVEL
Red (Bar)=Vacuum Black (Bar)=Vapor Bold (Bar)=Liquid
o
C R12 R22 R-134a
R407A
Vapor
R407A
Liquid
R404A
HP 62
R407C
Vapor
R407C
Liquid
R408A R409A R410A R502
R507A
AZ50"
o
F
10.0 3.21 5.80 3.13 5.94 7.19 7.14 5.43 6.75 6.60 3.06 9.83 6.59 7.44 50.0
11.1 3.36 6.03 3.29 6.19 7.46 7.41 5.67
7.01
6.86 3.21 10.20 6.84 7.72 52.0
12.2 3.50 6.26 3.45 6.44 7.74 7.70 5.91
7.28
7.11 3.36 10.57 7.10 8.01 54.0
13.3 3.66 6.51 3.61 6.71 8.03 7.98 6.16
7.56
7.38 3.52 10.94 7.35 8.30 56.0
14.4 3.81 6.76 3.79 6.98 8.33 8.27 6.41
7.84
7.65 3.68 11.34 7.62 8.59 58.0
15.6 3.97 7.01 3.96 7.26 8.63 8.57 6.68 8.13 7.93 3.86 11.73 7.89 8.90
60.0
16.7 4.14 7.27 4.14 7.54 8.94 8.88 6.94 8.43 8.21 4.03 12.14 8.17 9.21
62.0
17.8 4.30 7.54 4.32 7.83 9.26 9.19 7.22 8.74 8.50 4.21 12.56 8.46 9.54
64.0
18.9 4.48 7.81 4.51 8.13 9.59 9.50 7.50 9.05 8.80 4.39 12.99 8.74 9.86
66.0
20.0 4.66 8.09 4.70 8.44 9.92 9.83 7.79 9.37 9.10 4.58 13.42 9.04 10.20
68.0
21.1 4.83 8.37 4.90 8.76 10.26 10.17 8.09 9.69 9.42 4.77 13.87 9.34 10.54
70.0
22.2 5.01 8.67 5.11 9.08 10.61 10.51 8.39 10.03 9.74 4.97 14.32 9.66 10.89
72.0
23.3 5.20 8.97 5.32 9.41 10.97 10.86 8.70 10.37 10.06 5.17 14.79 9.98 11.25
74.0
24.4 5.39 9.28 5.53 9.75 11.34 11.22 9.03 10.72 10.40 5.38 15.27 10.30 11.62
76.0
25.6 5.59 9.59 5.75 10.10 11.71 11.59 9.35 11.07 10.74 5.59 15.76 10.63 11.99
78.0
26.7 5.79 9.90 5.98 10.46 12.09 11.96 9.69 11.43 11.09 5.81 16.26 10.97 12.38
80.0
27.8 6.00 10.23 6.21 10.82 12.48 12.34 10.03 11.81 11.44 6.03 16.77 11.32 12.77
82.0
28.9 6.21 10.57 6.45 11.19 12.88 12.73 10.39 12.19 11.81 6.26 17.29 11.67 13.17
84.0
30.0 6.43 10.91 6.69 11.57 13.28 13.13 10.75 12.58 12.18 6.50 17.83 12.03 13.58
86.0
31.1 6.64 11.26 6.94 11.97 13.70 13.54 11.12 12.98 12.56 6.74 18.37 12.40 13.99
88.0
32.2 6.87 11.61 7.19 12.37 14.12 13.96 11.50 13.39 12.94 6.99 18.93 12.78 14.42
90.0
33.3 7.10 11.98 7.46 12.78 14.56 14.39 11.88 13.80 13.34 7.23 19.50 13.16 14.86
92.0
34.4 7.33 12.35 7.72 13.20 15.01 14.82 12.28 14.23 13.74 7.50 20.08 13.55 15.30
94.0
35.6 7.57 12.73 7.99 13.63 15.46 15.26 12.69 14.66 14.16 7.76 20.68 13.95 15.76
96.0
36.7 7.81 13.12 8.28 14.06 15.92
15.72 13.10 15.10 14.58 8.03 21.28 14.36 16.22
98.0
37.8 8.06 13.51 8.57 14.51 16.39 16.18 13.52 15.55 15.01 8.30 21.90 14.78 16.70
100.0
38.9 8.32 13.92 8.86 14.97 16.87 16.66 13.96 16.01 15.45 8.59 22.53 15.20 17.18
102.0
40.0 8.58 14.32 9.15 15.44 17.36 17.14 14.41 16.48 15.90 8.88 23.18 15.63 17.67
104.0
41.1 8.84 14.74 9.46 15.92 17.86 17.63 14.86 16.96 16.35 9.17 23.84 16.08 18.17
106.0
42.2 9.11 15.17 9.77 16.41 18.37 18.13 15.32 17.45 16.82 9.47 24.51 16.52 18.69
108.0
43.3 9.39 15.61 10.10 16.91 18.89 18.65 15.79 17.95 17.29 9.78 25.20 16.99 19.21
110.0
44.4 9.67 16.06 10.42 17.43 19.42 19.17 16.28 18.46 17.78 10.10 25.90 17.45 19.74
112.0
45.6 9.95 16.51 10.76 17.94 19.97 19.70 16.78 18.97 18.27 10.42 26.61 17.93 20.29
114.0
46.7 10.25 16.97 11.10 18.48 20.52 20.25 17.28 19.50 18.77 10.74 27.34 18.41 20.85
116.0
47.8 10.54 17.45 11.45 19.03 21.08 20.81 17.80 20.04 19.29 11.08 28.09 18.91 21.41
118.0
48.9 10.85 17.93 11.81 19.59 21.66 21.37 18.33 20.59 19.81 11.43 28.85 19.41 21.99
120.0
50.0 11.16 18.42 12.17 20.16 22.23 21.95 18.87 21.15 20.34 11.78 29.62 19.92 22.59
122.0
51.1 11.47 18.92 12.54 20.74 22.83 22.54 19.42 21.72 20.89 12.14 30.41 20.45 23.19
124.0
52.2 11.79 19.43 12.92 21.33 23.44 23.14 19.99 22.30 21.44 12.50 31.22 20.99 23.80
126.0
53.3 12.12 19.94 13.31 21.94 24.06 23.75 20.56 22.90 22.01 12.88 32.04 21.52 24.43
128.0
54.4 12.45 20.48 13.70 22.56 24.68 24.38 21.14 23.50 22.58 13.26 32.88 22.08 25.07
130.0
55.6 12.79 21.01 14.11 23.19 25.32 25.02 21.75 24.12 23.17 13.64 33.74 22.65 25.72
132.0
56.7 13.14 21.56 14.52 23.84 25.98 25.67 22.36 24.74 23.77 14.04 34.61 23.22 26.39
134.0
57.8 13.49 22.12 14.94 24.50 26.64 26.34 22.99 25.38 24.37 14.44 35.50 23.81 27.06
136.0
58.9 13.85 22.69 15.37 25.18 27.32 27.01 23.63 26.03 24.99 14.86 36.41 24.40 27.75
138.0
60.0 14.21 23.27 15.81 25.87 28.01 27.70 24.28 26.69 25.62 15.28 37.34 25.01 28.46
140.0
61.1 14.58 23.86 16.26 26.57 28.71 28.41 24.94 27.36 26.27 15.70 38.29 25.62 29.18
142.0
62.2 14.96 24.46 16.71 27.29 29.43 29.13 25.63 28.04 26.92 16.14 39.26 26.26 29.92
144.0
63.3 15.34 25.07 17.17 28.02 30.15 29.87 26.32 28.74 27.59 16.59 40.24 26.90 30.67
146.0
64.4 15.73 25.69 17.65 28.77 30.90 30.61 27.03 29.45 28.27 17.05 41.25 27.54 31.43
148.0
65.6 16.13 26.32 18.13 29.54 31.65 31.39 27.76 30.17 28.96 17.51 42.28 28.21 32.22
150.0
