Cerabar M, Deltabar M, Deltapilot M Installation
Endress+Hauser 31
Typical installation arrangements
A0023109
Abb. 16:
A Impulse line vertical, version V1, alignment 90°
B Impulse line horizontal, version H1, alignment 180°
C Impulse line horizontal, version H2, alignment 90°
1 Deltabar M
2 Adapter plate
3 Mounting bracket
4 Pressure line
1
1
2
4
3
1
2
3
3
4
C
A
B
4
