Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
138 Endress+Hauser
9 Commissioning with the FF configuration
program
The device is configured at the factory for the Pressure measuring mode (Cerabar, Deltabar)
or Level measuring mode (Deltapilot). The measuring range and the unit in which the
measured value is transmitted correspond to the specifications on the nameplate.
Exceeding the maximum allowable working pressure!
Risk of injury due to bursting of parts! Warning messages are generated if pressure is too
high.
‣ If a pressure smaller than the minimum permitted pressure or greater than the
maximum permitted pressure is present at the device, the following messages are output
in succession (depending on the setting in the "Alarm behavior" (050) parameter):
"S140 Working range P" or "F140 Working range P"
"S841 Sensor range" or "F841 Sensor range"
"S971 Adjustment"
Use the device only within the sensor range limits.
Shortfall of the allowable working pressure!
Output of messages if pressure is too low.
‣ If a pressure smaller than the minimum permitted pressure or greater than the
maximum permitted pressure is present at the device, the following messages are output
in succession (depending on the setting in the "Alarm behavior" (050) parameter):
"S140 Working range P" or "F140 Working range P"
"S841 Sensor range" or "F841 Sensor range"
"S971 Adjustment"
Use the device only within the sensor range limits.
9.1 Function check
Carry out a post-installation and a post-connection check as per the checklist before
commissioning the device.
• "Post-installation check" checklist ä 37
• "Post-connection check" checklist ä 43
9.2 Commissioning with FF application
Note Dependencies when setting parameters!
‣ The device is configured at the factory for the Pressure measuring mode (Cerabar,
Deltabar) or Level measuring mode (Deltapilot). The measuring range and the unit in
which the measured value is transmitted, as well as the digital output value of the Analog
Input Block OUT, correspond to the data on the nameplate. Following a reset with
code 7864, the OUT parameter may have to be rescaled (see also Page 141,
Section 9.3 "Scaling the OUT parameter").
‣ The standard order configuration is illustrated on ä 59, Section 6.4.6 "Block model".
‣ The "xxxxxxxxxxx" characters used in the following sections are placeholders for the serial
number.
1. Switch on the device.
2. Note the DEVICE_ID. ä 58, Section 6.4.5 "Device identification and addressing" and
ä 8, Section 3.2.1 "Nameplate" for the device serial number.
3. Open the configuration program.
