Operation Cerabar M, Deltabar M, Deltapilot M
58 Endress+Hauser
6.4.5 Device identification and addressing
FOUNDATION Fieldbus identifies the device using its ID code and automatically assigns it a
suitable field address. The identity code cannot be changed.
The device appears in the network display once you have started the FF configuration
program and integrated the device into the network. The blocks available are displayed
under the device name.
If the device description has not yet been loaded, the blocks report "Unknown" or "(UNK)".
The devices report as follows (typical display in a configuration program after the connection
has been established):
Device name Serial number
 -
-
 EH_ Deltabar_M_5X _ 00000000000000
RS_00000000000 (RB2)
TRD1_00000000000 (PCD)
DP_FLOW_000000000000 (DPFLOW)
DIAGNOSTIC_000000000000 (DIAGNOSTIC)
DISPLAY_00000000000 (DISP)
AI1_000000000000 (AI)
AI2_000000000000 (AI)
DI_00000000000 (DI)
DO_00000000000 (DO)
ISEL_00000000000(ISB)
PID_00000000000(PID)
ARTH_00000000000(ARB)
CHAR_00000000000(SCB)
INTG_0000000000 (ITB)
-
 EH_ Cerabar_M_5X _ 00000000000000
EH_ Deltapilot_M_5X _ 00000000000000
RS_00000000000 (RB2)
TRD1_00000000000 (PCD)
DIAGNOSTIC_000000000000 (DIAGNOSTIC)
DISPLAY_00000000000 (DISP)
AI1_000000000000 (AI)
AI2_000000000000 (AI)
DI_00000000000 (DI)
DO_00000000000 (DO)
ISEL_00000000000(ISB)
PID_00000000000(PID)
ARTH_00000000000(ARB)
CHAR_00000000000(SCB)
INTG_0000000000 (ITB)
