Cerabar M, Deltabar M, Deltapilot M Document information
Endress+Hauser 5
1.2.4 Symbols for certain types of information
1.2.5 Symbols in graphics
1.2.6 Symbols at the device
1.2.7 Registered trademarks
KALREZ
®
, VITON
®
, TEFLON
®
Registered label of E.I. Du Pont de Nemours & Co., Wilmington, USA
TRI-CLAMP
®
Registered label of Ladish & Co., Inc., Kenosha, USA
FOUNDATION
TM
Fieldbus
Registered trademark of the FieldComm Group, Austin, USA
GORE-TEX
®
Registered label of W.L. Gore & Associates, Inc., USA
Symbol Meaning
A0011182
Permitted
Indicates procedures, processes or actions that are permitted.
A0011184
Forbidden
Indicates procedures, processes or actions that are forbidden.
A0011193
Tip
Indicates additional information.
A0015482
Reference to documentation
A0015484
Reference to page
A0015487
Reference to graphic
, , ... Series of steps
A0018343
Result of a sequence of actions
A0015502
Visual inspection
Symbol Meaning
1, 2, 3, 4, ... Item numbers
, , ... Series of steps
A, B, C, D, ... Views
Symbol Meaning
A0019159
Safety instructions
Observe the safety instructions contained in the associated Operating Instructions.
Connecting cable immunity to temperature change
Indicates that the connecting cables have to withstand a temperature of 85°C at least.
1.
2.
1.
2.
t 85°C>
