Operation options Cerabar PMC11, PMC21, PMP11, PMP21, PMP23
24 Endress+Hauser
Electrical connection: To transmitter with 4 to 20 mA output and elbow plug DIN 43 650,
reverse polarity protection
Display power supply: Not required, powered automatically from the power loop
Voltage drop: ≤ 5 V (corresponds to load: max. 250 Ω)
Rate of conversion: 3 measurements per second
Damping: 0.3 to 20 s (configurable)
Data backup: Non-volatile EEPROM
Error message: • HI: overrange
• LO: below range
Programming: Via 2 keys, menu-guided, display range scaling, decimal point, damping,
error message
Degree of protection: IP 65
Influence of temperature on the
display:
0.1% / 10 K
Electromagnetic compatibility
(EMC):
Interference emission as per EN 50081, interference immunity as per EN
50082
Permitted current load: Max. 60 mA
Ambient temperature: 0 to +60 °C (+32 to +140 °F)
Housing material: Pa6 GF30 plastic, blue
Front screen made from red PMMA
Order number: 52022914
7.1.4 Electrical connection
Pin assignment
L
WARNING
Is the supply voltage switched off?
Risk of electric shock!
‣
Switch off the supply voltage before connecting the device.
• PIN 1: L+ (supply voltage U
B
)
• PIN 2: L- (0 V)
• PIN 3: Not assigned
Supply voltage
The supply voltage (mostly 24 V DC) must be greater than the sum of the voltage drop U
s
at the sensor, the voltage drop of 5 V at the display and other voltage loss U
a
(such as
additional evaluation and power loss).
The following therefore applies: U
b
= U
s
+ 5 V + U
a
Post-connection check
Is the device or cable undamaged (visual check)?
Are all cable glands installed, securely tightened and leak-tight?
If supply voltage is present, is the device ready for operation and do values appear on the display module?
