Deltabar PMD75B PROFINET with Ethernet-APL Technical data
Endress+Hauser 83
Process connection and process adapter when using the separate housing
FEP cable
• IP69 (on sensor side)
• IP66 TYPE 4/6P
• IP68 (1.83 mH
2
O for 24 h) TYPE 4/6P
PE cable
• IP69 (on sensor side)
• IP66 TYPE 4/6P
• IP68 (1.83 mH
2
O for 24 h) TYPE 4/6P
Vibration resistance Single compartment housing
Measuring range Sine wave oscillation IEC62828-1 / IEC61298-3 Shock
10 mbar (0.15 psi) and 30 mbar (0.45 psi) (only up
to PN100)
10 Hz to 60 Hz: ±0.21 mm (0.0083 in)
60 Hz to 2000 Hz: 3 g
30 g
0.1 to 250 bar (1.5 to 3 750 psi) 10 Hz to 60 Hz: ±0.35 mm (0.0138 in)
60 Hz to 1000 Hz: 5 g
30 g
Aluminum dual compartment housing
Measuring range Sine wave oscillation IEC62828-1 / IEC61298-3 Shock
10 mbar (0.15 psi) and 30 mbar (0.45 psi) 10 Hz to 60 Hz: ±0.21 mm (0.0083 in)
60 Hz to 2000 Hz: 3 g
30 g
0.1 to 250 bar (1.5 to 3 750 psi) 10 Hz to 60 Hz: ±0.35 mm (0.0138 in)
60 Hz to 1000 Hz: 5 g
30 g
Stainless steel dual compartment housing
Measuring range Sine wave oscillation IEC62828-1 / IEC61298-3 Shock
10 mbar (0.15 psi) and 30 mbar (0.45 psi) (only up
to PN63)
10 Hz to 60 Hz: ±0.075 mm (0.0030 in)
60 Hz to 500 Hz: 1 g
15 g
0.1 to 250 bar (1.5 to 3 750 psi) 10 Hz to 60 Hz: ±0.15 mm (0.0059 in)
60 Hz to 500 Hz: 2 g
15 g
Dual compartment housing, L-form
Sine wave oscillation IEC62828-1 / IEC61298-3 Shock
10 Hz to 60 Hz: ±0.21 mm (0.0083 in)
60 Hz to 2000 Hz: 3 g
30 g
Electromagnetic
compatibility (EMC)
• Electromagnetic compatibility as per EN 61326 series and NAMUR recommendation
EMC (NE21)
• With regard to the safety function (SIL), the requirements of EN 61326-3-x are satisfied
• Maximum deviation with interference influence: < 0.5% of span with full measuring
range (TD 1:1)
For more details refer to the EU Declaration of Conformity.
