Deltabar PMD78B PROFINET with Ethernet-APL Mounting
Endress+Hauser 19
5.1.5 Orientation
Diaphragm seal on one side or both sides with temperature isolator
C
D
+ -
+ -
+ -
+ -
A
B
+ -
+ -
+ -
+ -
A0038658
A Design HP side: Transmitter horizontal, temperature isolator long
B Design HP side: Transmitter vertical, temperature isolator long
C Design HP side: Transmitter horizontal, temperature isolator short
D Design HP side: Transmitter vertical, temperature isolator short
