Endress+Hauser Profi Bus Levelflex M FMP40 Technical Information

Levelflex M FMP40
Endress+Hauser 13
Output
Output signal • 4 to 20 mA (invertible) with HART protocol
• PROFIBUS PA:
– signal coding: Manchester Bus Powered (MBP)
– data transmission rate: 31.25 KBit/s, voltage mode
• FOUNDATION Fieldbus (H1):
– signal coding: Manchester Bus Powered (MBP)
– data transmission rate: 31.25 KBit/s, voltage mode
Signal on alarm Error information can be accessed via the following interfaces:
• Local display:
– Error symbol
– Plain text display
• Current output, signal on error can be selected (e.g. according to NAMUR recommendation NE43)
• Digital interface
Linearization The linearization function of the Levelflex M allows the conversion of the measured value into any unit of
length or volume and mass or %. Linearization tables for calculating the volume in cylindrical tanks are
preprogrammed. Other tables of up to 32 value pairs can be entered manually or semi-automatically. The
creation of a linearization table with FieldCare is particularly convenient.
Data of the FOUNDATION
Fieldbus interface
Basic Data
Virtual communication references (VCRs)
Link Settings
Device Type 1012 (hex)
Device Revision 04 (hex)
DD Revision 02 (hex)
CFF Revision 02 (hex)
ITK Version 4.61
ITK-Certification Driver-No. www.endress.com / www.fieldbus.org
Link-Master (LAS) cabable Yes
Link Master / Basic Device selectable Yes; Default: Basic Devce
Number VCRs 24
Number of Link-Objects in VFD 24
Permanent Entries 1
Client VCRs 0
Server VCRs 24
Source VCRs 23
Sink VCRs 0
Subscriber VCRs 23
Publisher VCRs 23
Slot time 4
Min. Inter PDU delay 6
Max. response delay 10
