RIA45 Appendix
Endress+Hauser 59
Factory setting 100.00
Additional information Only visible if → Diff pressure is configured as the application.
Submenu "Linearization"
Navigation

Setup → Linearization
Description Only visible if → Diff pressure is configured as the application.
No lin points
Navigation

Setup → Linearization → No lin points
Description Number of points needed for linearization.
User entry 2...32
Factory setting 2
X-value 1...X-value 32
Navigation

Setup → Linearization → X-value 1...X-value 32
Description X-value for the linearization point in question
User entry Numerical value
1)
Factory setting 0.0000
Y-value 1...Y-value 32
Navigation

Setup → Linearization → Y-value 1...Y-value 32
Description Y-value for the linearization point in question
User entry Numerical value
1)
Factory setting 0.0000
Submenu "Analog in 1"/"Analog in 2"
Navigation

Setup → Analog in 1/Analog in 2
Additional information Settings for analog input 1 or analog input 2
Signal type
Navigation

Setup → Analog in 1/Analog in 2 → Signal type
Description Configures the input type.
Options off
Current
Voltage
RTD
TC
Factory setting Current
Additional information If "Signal type" is set to "Off", all the parameters under it are hidden.
