Page #12 background image
SS2100 Analyzer
24 4900002253 rev. C 9-30-20
Analyzer Technical Specifications
Refer to Equipment ratings for specifications related to the SS2100 analyzer.
Peripheral devices
For systems equipped with peripheral devices, e.g., probe assemblies, refer to
documentation provided by the manufacturer for instruction on installation,
operation, etc.
Equipment ratings
Equipment rating information for the SS2100 analyzer is included in Table 2-1
below. This information includes, but is not limited to, the following:
Supply voltage, power and current rating
Description of all input connections
Environmental conditions for which the equipment is designed (i.e.,
environmental temperature range, environmental relative humidity)
Degree of ingress protection (IP)
Table 2-1 SS2100 analyzer equipment ratings and specifications
Electrical & Communications
Input Voltages (Electronics)
1
1. Supply voltage not to exceed 10% of nominal.
2. Application dependent.
120 or 240 VAC ±10%, 50-60 Hz, 60 W
(2 power connections) - Standard
18-24 VDC, 1.6 A maximum - Optional
Input Voltages (SCS Heater,
Optional)
120 VAC or 240 VAC +/-10%, 50-60 Hz single
phase, 200 W
Maximum Current 2 A maximum at 120 VAC
1 A maximum at 240 VAC
1.6 A maximum at 24 VDC
DO Contact Rating (Inductive
Load)
250 VAC, 3 A NO contact, 1.5 A NC contact
24 VDC, 1 A NO and NC contact
Communication Analog: (2) 4-20 mA Isolated, 1200 ohms at
24 VDC maximum (concentration only) -
Optional
Serial: RS-232C and Ethernet
Protocol: Modbus Gould RTU or Daniel RTU or
ASCII
Digital Output (5): Concentration Alarm, General Fault, Valida-
tion Fail
2
, Validation 1 Active
2
, Validation 2
Active
2
